Nvidia’s latest GTX video card is now avilable! (GeForce GTX690) Lets find out the specifications of GeForce GTX690 video card. Here is the reference card specifications. NVIDIA’s Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest DirectX 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation and the new geometry engine draws triangles twice as fast. The result is world class performance and the highest image quality in an elegant and power efficient graphics card.
Nvidia GeForce GTX690 Specifications
GTX 690 GPU Engine Specs
CUDA Cores: 3072
Base Clock (MHz): 915
Boost Clock (MHz): 1019
Texture Fill Rate (billion/sec): 234
GTX 690 Memory Specs:
Memory Speed (Gbps): 6.0
Standard Memory Config: 4096 MB (2048 MB per GPU) GDDR5
Memory Interface Width: 512-bit (256-bit per GPU)
Memory Bandwidth (GB/sec): 384
GTX 690 Support:
OpenGL: 4.2
Bus Support: PCI Express 3.0
Certified for Windows 7: Yes
Supported Technologies: 3D Vision, 3D Vision Surround, CUDA, DirectX 11, PhysX, SLI, TXAA, Adaptive VSync, GPU Boost
SLI Options: Quad
GTX 690 GPU Display Support:
Multi Monitor: 4 displays
Maximum Digital Resolution: 2560×1600
Maximum VGA Resolution: 2048×1536
Supports HDCP, HDMI, Two Dual Link DVI-I. One Dual link DVI-D. One Mini-Displayport 1.2
GTX 690 Graphics Card Dimensions:
Length: 11.0 inches
Height: 4.376 inches
Width: Dual-slot
Thermal and Power Specs:
Maximum GPU Tempurature (in C): 98 C
Maximum Graphics Card Power (W): 300 W
Minimum System Power Requirement (W): 650 W
Supplementary Power Connectors: Two 8-pin
3D Vision Ready:
3D Blu-Ray, 3D Gaming, 3D Vision Live (Photos and Videos)
